Outcut catamaran

Outcut Cruiser 29.5 is the towable catamaran with variable width and a unique habitability in just nine metres and an unprecedented efficiency.
Cruiser 29.5 represents state-of-the-art technique and opens new mobility horizons when travelling by water and land. Hulls made entirely in vacuum carbon composite to ensure lightness and structural resistance. Waterlines studied to maximize the penetration coefficient, ensuring stability and efficiency. Draught of only thirty centimetres.
Dynamic Hull Range: explore new horizons
The innovative DHR (Dynamic Hull Range) system allows changing the hull width from 2.5 metres on the trailer or in the port, to 3.5 metres during navigation, without compromising the habitability aspects. Cruiser 29.5 represents state-of-the-art technique and opens new mobility horizons when travelling by water and land.
A new concept of efficiency
An unprecedented power-performance ratio: boasting two off-board 20 horse power engines, it has a maximum speed of 15 knots and a cruising speed of 13 knots. Its exceptionally high efficiency makes it particularly suitable for electric powered systems: a zero impact cruiser for comfortable sailing with no impact on the sea ecosystem. The catamaran can be equipped with an auxiliary sail and a simplified and efficient mast, that combines pure pleasure with a performance increase of over 30%.
A technical concentrate
The hulls have been carefully designed to obtain utmost fluodynamic efficiency, they are entirely made in vacuum carbon and epoxy resin composite to maximize the weight/mechanical performance ratio and are equipped with water-tight compartments that make them unsinkable. The reinforced bows and draft of only 30 centimetres allow the Cruiser 29.5 to reach shore.
Hulls the hulls are made in carbon and epoxy resin composite, vacuum method, 15 mm core. Watertight compartments, bow crash box, local reinforcements and anti-slip surf grip surface. Unsinkable hulls with 4 peaks per hull and fuel and water tank compartment above the air draft. Fuel tanks 2×70 l. Fresh water tank 1×100 l. No. 6 aluminium bollards. No. 8 handrails.
Cabin_ Construction of living area and cockpit in carbon and epoxy resin composite, 15 mm and 25 mm core. Anti-slip surf grip walkable surface. Maximum cabin height 174 cm. Lateral windows in 8 mm anti-UV lexan. Access to deck through no. 2 40×40 cm hatches. Two internal 20 cm portholes for air circulation.
Habitability with no compromises
The deck spaces are conceived to provide maximum comfort for up to eight passengers. There are no technical elements on the bridge to the advantage of the walkways from the spacious sun deck to the cockpit. The hulls are equipped with fresh water tanks, fuel tanks, batteries and two capacious 100 litre peaks. The cockpit also has a further two capacious 520 litre peaks. The inviting living area of the cruiser is designed to easily accommodate up to four berths, to provide outstanding comfort even on long journeys.
The interior is fitted with a double bed (160x210cm) cabin at the bow, a bathroom with shower, a dinette with a table for six which can be turned into a double bed (140x190cm) if so required. The two hatches allow quick access to the deck, finished with anti-slip surf grip surface. The areas are outstandingly bright thanks to the large portholes and there is front visibility even from the cockpit. The dinette can be further equipped with a walled kitchen featuring an undertop single sink and a two burner hob.
Cabin_ Construction of living area and cockpit in carbon and epoxy resin composite, 15 mm and 25 mm core. Anti-slip surf grip walkable surface. Maximum cabin height 174 cm. Lateral windows in 8 mm anti-UV lexan. Access to deck through no. 2 40×40 cm hatches. Two internal 20 cm portholes for air circulation.
Layout_ Central access at cockpit level on dinette that can be turned into a double bed (190x 140 cm), with standard nautical pillows and table that can be lowered, pantry and peaks under the sofa. Cabin internal height 174 cm. Bathroom with shower, sink and retractable chemical toilet, walled storage compartments, led lights. Walled kitchen with two- burner hob and sink with undertop compartments. Night area at the bow with 160×210 cm double bed, max height from mattress to ceiling 110 cm, leg lights, 130x80x40 cm storage peak under mattress, 40×40 panoramic window and hatch.
Electrics_ 12V/80 Ah battery, electric panel with automatic switches and general battery master-switch. 12V plugs and (6V) USB in dinette and bow. Lighting: 6 led spotlights in the cabin and 4 led navigation lights. Autoclave. Two automatic bilge pumps.
Bridge_ 50 mm Rudder wheel. Independent fuel level indicators for 2 tanks. Navigation light switches and horn. USB port. Universal engine remote control compartment.
Colours and finishes
The catamaran is conceived as a modular system which can be configured to meet the specific requirements of the owner and be updated over time. Outcut 29.5 can also be customized selecting a combination of shades for the hulls, the living area and the deck.

Credits

Design
Outcut s.r.l., Italy

Manufacturer
Outcut s.r.l., Italy

Year of production
2019
