Lumen Galaxy

The Galaxy is an urban pole-top luminaire using highly energy-efficient LED technology for street and public space lighting predominantly. The luminaire can be installed at heights of up to 6 meters. Body construction is made of aluminum by casting or injection molding technology and is based on a very sleek and slim aerodynamic design to be resistant against the windy outdoor conditions. Unique ellipse light halo is variable and offers 2 set up positions like for horizontal moving and angle rotation. Elliptical halo is ready to use both sides with LED lenses for park lighting or one half just for street lighting into required spots. Compact fixation head with electric-components as a part of main body allows the luminaire to be fixed on the lamppost in the diameter up to 70mm. The product is waterproof, saving energy and well cooling the LED panels inside against overheating. The dimensions: 821mm (length), 301mm (width), 407mm (height), 28mm (slim LED frame of halo). Light parameters: luminous flux from 2000lm to 9000lm, wireless control, autonomous light intensity during sunset and easy maintenance service through removable glass panels and top case.


David Polášek, Novo Design

Elektro Lumen, Czech Republic

Year of production

David Polasek
